Microscopes Microscope stand Options
Upright Leica DM6 CS
Leica DM6 CFS
Leica DM6 CFS w/o TL axis
Inverted Leica DMi8 CS
Leica DMi8 CEL Compact
Leica DMi8 CEL Advanced
Vibration isolation Isolation options Specifications
Anti-vibration table Yes (active/passive)
Microscope stage Stage options Specifications
Autofocus Optional, for Leica DMi8 CS
Motorfocus (stand) Travel range depending on mechanics of microscope/
minimum step size 50 nm, adjustable in increments of < 4 nm
Z-Galvonometer Selectable z-modes (Galvo Flow/discrete steps) available,
1500 μm range / minimum step size 20 nm, adjustable in increments
of < 1.5 nm
500 μm restricted range/minimum step size 20 nm, adjustable in
increments of < 0.5 nm
Continuous wave lasers Laser type Specifications
VIS Solid state laser 40mW: 448 nm
Solid state laser 20mW: 488 nm
Solid state laser 20mW: 514 nm
Solid state laser 20mW: 552 nm
Solid state laser 30mW: 638 nm
Diode 40mW: 442 nm
Ar 65mW: 458, 476, 488, 496, 514 nm
HeNe, 2mW: 594 nm
HeNe, 10mW: 633 nm
DPSS, 20mW: 561 nm
UV UV OPSL 80mW: 355 nm
Diode, 50mW: 405 nm
Pulsed lasers Laser type Specifications
IR Power & tuning range depending on selected model
